Alpine S2-A60M
Alpine's Next Generation S-Series S2-A60M mono subwoofer amplifier makes it a lot easier to get great bass in your ride, delivering up to 600 watts RMS power to your sub. A variable bass boost allows you to dial in some extra kick and impact for more low-frequency enjoyment.
Product highlights:
mono subwoofer amplifier
330 watts RMS x 1 at 4 ohms
600 watts RMS x 1 at 2 ohms
600 watts RMS x 1 at 1 ohm
variable low-pass filter (50-400 Hz, 24 dB/octave)
variable bass boost (0-12 dB at 50 Hz)
RMS Power Ratings
Per Channel into 1 Ohms, 14.4V (≤1%THD+N): 1 x 600W
Per Channel into 2 Ohms, 14.4V (≤1%THD+N): 1 x 600W
Per Channel into 4 Ohms, 14.4V (≤1%THD+N): 1 x 330W
Sound Tuning
Crossover: Variable LPF: 50-400Hz (-24dB/oct)
Bass EQ (+12dB)
General
Power Requirements: 14.4 V.DC (9 - 16 V allowable)
Input Sensitivity (RCA Input): Hi: 0.5V - 10V / Low: 0.2V - 4.0V
High Level Input with automatic power on
Frequency Response (+0, -3dB: 1W into 4 ohms): 10Hz – 400Hz
THD+N (@ 10W into 4 Ohms): <0.03%
Damping Factor: >1000
Weight: 2.2kg
Dimensions
Heat Sink (WxHxD) mm: 220 x 57 x 210
